Engineering via SICAM WEB
436 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
• Click Select a file to open the selection dialog
• Select the source directory and the source file (the file type must be .plc)
• Click on the button in order to start the import
The target device starts the loading procedure. The duration of the loading procedure de-
pends on the program size and the used communication connection.
Note
During the generation procedure the menu must not be left. The selection of another webpage may lead to
the occurrence of undefined states.
The program file is checked upon validity. If the data is invalid, an error indication is displayed.
If the data is valid, the following dialog appears:
• Click on the button
After successful upload, the content of the IL is displayed in the logic page and an automatic
Syntax Check is performed.
The result of the syntax check is displayed in the bottom toolbar. In case of error you will find
further details in the status log.
