Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 449
DC8-037-2.02, Edition 10.2017
• If you want to perform the restart, click on the button
à unsaved changes will be rejected thereby!
The following information will appear during a restart:
At the bottom of the dialog the current startup time is displayed. Depending on the size of the
engineering data, the startup time can take up to 15 minutes.
A successful restart of the device is shown by the following dialog:
• Click in order to quit the session with the target device
• Click the suitable hyperlink in order to return to the Logon page of the previously started
target device
• If in the target device the parameter Autoconfiguration was set to YES, the IP address
is set to 169.254.0.1; that remains until it is assigned anew by the set DHCP server (see
9.1.2.7, Autoconfiguration)
Caution
A startup concernes also the automation function (if used). You find further information in section 9.2.2,
Commissioning and Test.
Note
With the initial commissioning, the startup may last up to 15 minutes, since at this the files on the SD card
will be unpacked and the system folders
on the SD card are created.
