Service
474 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
Connection Status
Name Color Function LED Meaning
LK1 Yellow Link X1 ˜ Physical connection to the Ethernet Hub
™
• Startup Connection not established
• Startup
PK1 Yellow Package X1 ž Activity (TCP frame sent/received)
™ Startup
OH2 Yellow Off hook X2 ž Sending message
˜ Connection with minimum one physical partner set up
(dial-up traffic)
™
• Connection not established
• Startup
RTX2 Yellow Receive/transmit
data X2
ž Activity on send/receive line
™ Startup
OH3 Yellow Off hook X3 ž Sending message
˜ Connection with minimum one physical partner set up
(dial-up traffic)
™
• Connection not established
• Startup
RTX3 Yellow Receive/transmit
data X3
ž Sending or receiving message
™ Startup
LK4 Yellow Link X4 ˜ Physical connection to the Ethernet Hub
™
• Startup Connection not established
• Startup
PK4 Yellow Package X4 ž Activity (TCP frame sent/received)
™ Startup
OH6 Yellow Off hook X6 ž Sending message
˜ Connection with minimum one physical partner set up
(dial-up traffic)
™
• Connection not established
• Startup
RTX6 Yellow Receive/transmit
data X6
ž Sending or receiving message
™ Startup
LK7 Yellow Link X7 ˜ Connection established
§ 0.5 s: net search, not registered, turning off
1 s: registered to mobile network
2 s: error (SIM, registration, IPsec, …)
™
• Connection not established
• Startup
PK7 Yellow Package X7 ž Data exchange with GPRS modem
™ Startup
