In the submenu All Events all process events
and diagnosis events are displayed in chrono-
logical order (most recent entry first).
In the header you can see which entry you have
selected and the amount of all entries.
After opening the list, the most recent entry is
automatically selected.
You can navigate through the entire list via function keys ▼ and ▲.
In the selected entry you can see detailed information on the selected entry (date,
timestamp, etc.).
Using the function key TOP, you go to the beginning of the list (and select the first entry).
The oscillating function key TOP shows that a new event is active.
• Press the oscillating function key TOP to refresh the entire list
The function key TOP will not be oscillating if you did select the first entry and a new event
occurs. In this case, however, the list will be refreshed.
Submenu Submenu Display/settings Meaning/range
3.1
Events
3.1.1
All Events
Event name
• Freely parameterizable text
(applies for process events)
• Always beginning with “Dia”
(applies for diagnosis
events)
Status
• Freely parameterizable text
(applies for process events)
• Coming, going (applies for
diagnosis events)
Quality bit Applies for process events
(TI 30 and TI 31) only:
?: not topical
!: invalid
#: blocked
$: substituted
Date Date of the selected event
Time stamp Timestamp of the selected
event
Time quality bit !: invalid (optional)
Indication of daylight-saving
time
S: daylight-saving time (op-
tional)
