Page #239 background imageLoading...
Page #239 background image
Functions
2.33 Interturn Protection (ANSI 59N (IT))
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
239
2.33.3 Settings
2.33.4 Information List
Addr. Parameter Setting Options Default Setting Comments
5501 INTERTURN PROT OFF
ON
Block relay
OFF Interturn Protection
5502 U Interturn > 0.3 .. 130.0 V 2.0 V Pick up Value U Interturn>
5503 T-U Interturn > 0.00 .. 60.00 sec; 0.50 sec Time Delay of Trip Command
5504 RESET RATIO 50 .. 95 % 80 % Reset Ratio of U Interturn>
No. Information Type of In-
formation
Comments
5413 >I/T BLOCK SP >BLOCK interturn fault protection
5421 I/T OFF OUT Interturn fault prot. is switched OFF
5422 I/T BLOCKED OUT Interturn fault protection is BLOCKED
5423 I/T ACTIVE OUT Interturn fault protection is ACTIVE
5426 I/T picked up OUT Interturn fault protection picked up
5427 I/T TRIP OUT Interturn fault protection TRIP
