Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
542
A.1 Ordering Information and Accessories
A.1.1 Ordering Information
A.1.1.1 Order Key
1)
for each binary input the pickup threshold ranges are interchangeable via plug-in jumpers
6 7 8 9 101112 131415 171819
Multi-Functional Pro-
tective Relay with
Local Control
7UM62 ——0 +
Housing, Number of Binary Inputs and Outputs Pos. 6
Housing
1
/
2
19'', 7 BI, 12 BO, 1 Live Status Contact 1
Housing
1
/
1
19'', 15 BI, 20 BO, 1 Live Status Contact 2
Graphic Display, Housing
1
/
2
19'', 7 BI, 12 BO, 1 Live Status Contact 3
Rated current Pos. 7
I
N
= 1 A, Iee (sensitive) 1
I
N
= 5 A, Iee (sensitive) 5
Auxiliary Voltage (Power Supply, Binary Input Threshold) Pos. 8
24 to 48 VDC, binary input threshold 19 V
1)
2
60 to 125 VDC, binary input threshold 19 V
1)
4
110 to 250 VDC, 115 to 230 VAC, binary input threshold 88 VDC
1)
5
220 to 250 VDC, 115 to 230 VAC, binary input threshold 176 VDC
1)
6
Construction Pos. 9
Surface-mounting case for panel, 2-tier terminals top/bottom B
Flush mounting case, plug-in terminals (2/3-pole connector) D
Flush mounting case, screw-type terminals (direct connection / ring and spade lugs) E
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, German Language (Language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, Language English (Language can be changed) B
Region US, 60 Hz, ANSI, American English Language (Language can be changed) C
System Interfaces or Analog Output (Port B) Pos. 11
No system interface 0
IEC Protocol, electrical RS 232 1
IEC-Protocol, electrical RS 485 2
IEC Protocol, Optical, 820 nm, ST Connector 3
Analog outputs 2 x (0 to 20 mA) 7
for more interface options see Additional Information L 9
