Technical Data
4.1 General
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
461
4.1.5 Electrical Tests
Regulations
Insulation Test
EMC Tests for Immunity (Type Tests)
Standards: IEC 60255 (product standards)
IEEE C37.90.0/.1/.2
UL 508
VDE 0435
See also standards for individual tests
Standards: IEC 60255-5 and IEC 60870-2-1
High voltage test (routine test) current inputs,
voltage inputs, output relays
2.5 kV (rms), 50 Hz
High voltage test (routine test)
Auxiliary voltage and binary inputs
DC 3.5 kV
High voltage test (routine test)
Measuring transducers MU1-MU3
DC 3.0 kV
Impulse voltage test (type test)
only isolated communication and
time synchronization interfaces or analog outputs
(port A –D)
500 V (rms), 50 Hz
Impulse voltage test (type test)
All circuits except communication and time synchro-
nization interfaces, analog outputs class III
5 kV (peak): 1.2/50 µs: 0.5 J, 3 positive and 3 negative
impulses in intervals of 5 s
Standards: IEC 60 255-6 and -22 (product standards)
EN 61000-6-2 (generic standard)
VDE 0435 Part 301
DIN VDE 0435-110
High frequency test IEC 60255-22-1, Class III and
VDE 0435 Part 303, Class III
2.5 kV (peak); 1 MHz; τ = 15 µs; 400 surges per s; test
duration 2 s; R
i
= 200 Ω
Electrostatic discharge
IEC 60 55-22-2, Class IV
and IEC 61000-4-2, Class IV
8 kV contact discharge; 15 kV air discharge, both polar-
ities; 150 pF; R
i
= 330 Ω
Irradiation with HF field, frequency sweep
IEC 60255-22-3, Class III
IEC 61000-4-3, Class III
10 V/m; 80 MHz to 1000 MHz;
10 V/m; 800 MHz to 960 MHz;
20 V/m; 1.4 GHz to 2.0 GHz;
80 % AM; 1 kHz
Irradiation with HF field, single frequencies
IEC 60255-22-3,
IEC 61000-4-3,
amplitude-modulated
Class III: 10 V/m
80/160/450/900 MHz 80 % AM 1 kHz; duty cycle > 10 s
Fast transient disturbance/burst
IEC 60255-22-4 and
IEC 61000-4-4, Class IV
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms; repetition
rate 300 ms; both polarities: R
i
= 50 Ω; test duration 1
min
High energy surge voltages (SURGE),
IEC 61000-4-5 Installation Class 3
Pulse: 1.2/50 µs
