Technical Data
4.34 Temperature Detection by Thermoboxes
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
510
4.34 Temperature Detection by Thermoboxes
Temperature Detectors
Thresholds for Indications
connectable thermoboxes 1 or 2
Number of temperature detectors per thermobox Max. 6
Measuring Method Pt 100 Ω or Ni 100 Ω or Ni 120 Ω
Mounting Identification „Oil“ or „Ambient“ or „Winding“ or „Bearing“ or „Other“
for each measuring point:
Stage 1 –58 °F to 482 °F (–50 °C to
250 °C)
or ∞ (no indication)
Increments 1 °F
Increments 1 °C
Stage 2 –58 °F to 482 °F
(–50 °C to 250 °C)
or ∞ (no indication)
Increments 1 °F
Increments 1 °C
