Siemens SIPROTEC 7UM62 User Manual

Functions
2.7 Power System Data 2
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
64
2.7.4 Information List
No. Information Type of In-
formation
Comments
501 Relay PICKUP OUT Relay PICKUP
511 Relay TRIP OUT Relay GENERAL TRIP command
576 IL1 S1: VI Primary fault current IL1 Side1
577 IL2 S1: VI Primary fault current IL2 Side1
578 IL3 S1: VI Primary fault current IL3 Side1
579 IL1 S2: VI Primary fault current IL1 Side2
580 IL2 S2: VI Primary fault current IL2 Side2
581 IL3 S2: VI Primary fault current IL3 Side2
5012 UL1E: VI Voltage UL1E at trip
5013 UL2E: VI Voltage UL2E at trip
5014 UL3E: VI Voltage UL3E at trip
5015 P: VI Active power at trip
5016 Q: VI Reactive power at trip
5017 f: VI Frequency at trip
