Functions
2.49 Auxiliary Functions
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
332
Accumulated Shutdown Currents
The shutdown currents for each phase, which are indicated at every trip command individually for side 1 and
side 2, are accumulated and stored.
The counter and memory levels are secured against loss of auxiliary voltage.
Setting / Resetting
Setting or resetting of these statistical counters takes place under the menu item ANNUNCIATION STATIS-
TIC by overwriting the counter values displayed.
2.49.2.2 Information List
No. Information Type of In-
formation
Comments
- #of TRIPs= PMV Number of TRIPs
409 >BLOCK Op Count SP >BLOCK Op Counter
1020 Op.Hours= VI Counter of operating hours
30607 ΣIL1 S1: VI Accumulation of interrupted curr. L1 S1
30608 ΣIL2 S1: VI Accumulation of interrupted curr. L2 S1
30609 ΣIL3 S1: VI Accumulation of interrupted curr. L3 S1
30610 ΣIL1 S2: VI Accumulation of interrupted curr. L1 S2
30611 ΣIL2 S2: VI Accumulation of interrupted curr. L2 S2
30612 ΣIL3 S2: VI Accumulation of interrupted curr. L3 S2
