A.6 Functional Scope
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
571
A.6 Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 FAULT VALUE Disabled
Instant. values
RMS values
Instant. values Fault values
112 O/C PROT. I> Disabled
Side 1
Side 2
Side 2 Overcurrent Protection I>
113 O/C PROT. I>> Disabled
NonDirec. SIDE1
NonDirec.SIDE 2
Direc. SIDE1
Direc. SIDE2
NonDirec.SIDE 2 Overcurrent Protection I>>
114 O/C PROT. Ip Disabled
IEC SIDE 1
ANSI SIDE 1
IEC SIDE 2
ANSI SIDE 2
Disabled Inverse O/C Time Protection
116 Therm.Overload Disabled
Enabled
Enabled Thermal Overload Protection
117 UNBALANCE LOAD Disabled
Enabled
Enabled Unbalance Load (Negative Se-
quence)
118 O/C STARTUP Disabled
Side 1
Side 2
Disabled Startup O/C protection
120 DIFF. PROT. Disabled
Generator/Motor
3 phase transf.
Generator/Motor Differential Protection
121 REF PROT. Disabled
Gen. with IEE2
Gen. w. 3I0-S2
Transformer S1
Transformer S2
Disabled Restricted earth fault protection
130 UNDEREXCIT. Disabled
Enabled
Enabled Underexcitation Protection
131 REVERSE POWER Disabled
Enabled
Enabled Reverse Power Protection
132 FORWARD POWER Disabled
Enabled
Enabled Forward Power Supervision
133 IMPEDANCE PROT. Disabled
Enabled
Enabled Impedance Protection
135 OUT-OF-STEP Disabled
Enabled
Enabled Out-of-Step Protection
140 UNDERVOLTAGE Disabled
Enabled
Enabled Undervoltage Protection
141 OVERVOLTAGE Disabled
Enabled
Enabled Overvoltage Protection
142 FREQUENCY Prot. Disabled
Enabled
Enabled Over / Underfrequency Protection
