Appendix
A.4 Default Settings
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
567
1)
Generator Circuit Breaker
2)
De-excitation
3)
Emergency Tripping
4)
Only for 7UM622
A.4.4 Function Keys
Table A-5 Applies to all devices and ordered variants
BO8 I> TRIP 1815 O/C I> TRIP
1)
S/E/F TRIP 5193 Stator earth fault protection TRIP
1)
U>> TRIP 6573 Overvoltage U>> TRIP
1)
f1 TRIP 5236 f1 TRIP
1)
f2 TRIP 5237 f2 TRIP
1)
Exc<3 TRIP 5343 Underexc. prot. char. 3 TRIP
1)
Exc<U<TRIP 5346 Underexc. prot. char.+Uexc< TRIP
1)
Pr TRIP 5097 Reverse power: TRIP
1)
Pr+SV TRIP 5098 Reverse power: TRIP with stop valve
1)
I2 Θ TRIP 5161 Unbalanced load: TRIP of thermal stage
1)
Diff TRIP 5671 Differential protection TRIP
1)
BO9 I> TRIP 1815 O/C I> TRIP
2)
S/E/F TRIP 5193 Stator earth fault protection TRIP
2)
U>> TRIP 6573 Overvoltage U>> TRIP
2)
f2 TRIP 5237 f2 TRIP
2)
Exc<3 TRIP 5343 Underexc. prot. char. 3 TRIP
2)
Exc<U<TRIP 5346 Underexc. prot. char.+Uexc< TRIP
2)
Pr+SV TRIP 5098 Reverse power: TRIP with stop valve
2)
I2 Θ TRIP 5161 Unbalanced load: TRIP of thermal stage
2)
Diff TRIP 5671 Differential protection TRIP
2)
BO10 I> TRIP 1815 O/C I> TRIP
3)
S/E/F TRIP 5193 Stator earth fault protection TRIP
3)
f2 TRIP 5237 f2 TRIP
3)
I2 Θ TRIP 5161 Unbalanced load: TRIP of thermal stage
3)
Diff TRIP 5671 Differential protection TRIP
3)
BO11 No functions configured
(reserve)
--
BO12 reserved for Breaker
failure protection
--
BO13 ... 20 No functions configured
(reserve)
--
4)
Binary Output Allocated Function Function No. Description
Function Keys Allocated Function
F1 Display of Operational Annunciations
F2 Display of Primary Operational Values
F3 Jumping to heading for last eight fault annunciations
F4 Jumping to the reset menu of the min/max values
