Appendix
A.4 Default Settings
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
566
A.4.2 Binary Input
Table A-3 Binary input presettings for all devices and ordering variants
1)
Only Busbar Connection
2)
Only for 7UM622
A.4.3 Binary Output
Table A-4 Output relay presettings for all devices and ordering variants
Binary Input Allocated Function Function No. Description
BI1 >SV tripped 5086 >Stop valve tripped
BI2 >Uexc fail. 5328 >Exc. voltage failure recognized
BI3 >BLOCK f1 5206 >BLOCK stage f1
>BLOCK U< 6506 >BLOCK undervoltage protection U<
>S/E/F IEE off 5176 >Switch off earth current detec.(S/E/F)
1)
BI4 >FAIL:Feeder VT 361 >Failure: Feeder VT (MCB tripped)
>Useal-inBLK 1950 >O/C prot. : BLOCK undervoltage seal-in
>BLOCK U/V 6503 >BLOCK undervoltage protection
BI5 >Ext trip 1 4526 >Trigger external trip 1
BI6 >Ext trip 2 4546 >Trigger external trip 2
BI7 >Trig.Wave.Cap. 4 >Trigger Waveform Capture
BI8 ... 15 No functions configured
(reserve)
--
2)
Binary Output Allocated Function Function No. Description
BO1 Error PwrSupply 147 Error Power Supply
Fail Battery 177 Failure: Battery empty
BO2 Relay TRIP 511 Relay GENERAL TRIP command
BO3 I> TRIP 1815 O/C I> TRIP
Diff TRIP 5671 Differential protection TRIP
Imp.Z1< TRIP 3977 Imp.: Z1< TRIP
Imp.Z1B< TRIP 3978 Imp.: Z1B< TRIP
Imp.Z2< TRIP 3979 Imp.: Z2< TRIP
Imp.T3> TRIP 3980 Imp.: T3> TRIP
I>> TRIP 1809 O/C I>> TRIP
O/C Ip TRIP 1900 O/C Ip TRIP
BO4 IEE>> TRIP 1223 IEE>> TRIP
U0> TRIP 5187 Stator earth fault: U0 stage TRIP
S/E/F TRIP 5193 Stator earth fault protection TRIP
BO5 U< TRIP 6539 Undervoltage U< TRIP
U> TRIP 6570 Overvoltage U> TRIP
U>> TRIP 6573 Overvoltage U>> TRIP
BO6 f1 TRIP 5236 f1 TRIP
f2 TRIP 5237 f2 TRIP
BO7 Exc<3 TRIP 5343 Underexc. prot. char. 3 TRIP
Exc<U<TRIP 5346 Underexc. prot. char.+Uexc< TRIP
