2.5 Power System Data 1
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
61
2.5.3 Information List
249 SN TRANSFORMER 0.20 .. 5000.00 MVA 5.30 MVA Rated Apparent Power of
the Transformer
251 UN GEN/MOTOR 0.40 .. 800.00 kV 6.30 kV Rated Primary Voltage
Generator/Motor
252 SN GEN/MOTOR 0.20 .. 5000.00 MVA 5.27 MVA Rated Apparent Power of
the Generator
270 Rated Frequency 50 Hz
60 Hz
50 Hz Rated Frequency
271 PHASE SEQ. L1 L2 L3
L1 L3 L2
L1 L2 L3 Phase Sequence
272 SCHEME Busbar
Unit transf.
Busbar Scheme Configuration
274A ATEX100 YES
NO
NO Storage of th. Replicas w/o
Power Supply
275 FACTOR R SEF 1.0 .. 200.0 37.0 Ratio Prim./Sec. R SEF
276 TEMP. UNIT Celsius
Fahrenheit
Celsius Unit of temperature mea-
surement
280 TMin TRIP CMD 0.01 .. 32.00 sec 0.15 sec Minimum TRIP Command
Duration
281 BkrClosed I MIN 5A 0.20 .. 5.00 A 0.20 A Closed Breaker Min.
Current Threshold
1A 0.04 .. 1.00 A 0.04 A
295 TRANSDUCER 1 10 V
4-20 mA
20 mA
10 V Transducer 1
296 TRANSDUCER 2 10 V
4-20 mA
20 mA
10 V Transducer 2
297 TRANSDUCER 3 with filter
without filter
with filter Transducer 3
No. Information Type of In-
formation
Comments
361 >FAIL:Feeder VT SP >Failure: Feeder VT (MCB tripped)
5002 Operat. Cond. OUT Suitable measured quantities present
5145 >Reverse Rot. SP >Reverse Phase Rotation
5147 Rotation L1L2L3 OUT Phase Rotation L1L2L3
5148 Rotation L1L3L2 OUT Phase Rotation L1L3L2
Addr. Parameter C Setting Options Default Setting Comments
