Siemens SIPROTEC 7UM62 User Manual

Technical Data
4.1 General
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
462
EMC Tests For Noise Emission (Type Test)
4.1.6 Mechanical Stress Tests
Vibration and Shock Stress During Stationary Operation
Auxiliary voltage Common mode: 2 kV; 12 Ω; 9 µF
Diff. mode: 1 kV; 2 Ω; 18 µF
Measuring Inputs, Binary Inputs, Relay
Outputs
Common mode: 2 kV; 42 Ω; 0.5 µF
Diff. mode: 1 kV; 42 Ω; 0.5 µF
Line conducted HF, amplitude modulated
IEC 61000-4-6, Class III
10 V; 150 kHz to 80 MHz; 80 % AM; 1 kHz
Power System Frequency Magnetic Field
IEC 61000-4-8, Class IV
IEC 60255-6
30 A/m; continuous; 300 A/m for 3 s; 50 Hz
0.5 mT; 50 Hz
Oscillatory Surge Withstand Capability
IEEE Std C37.90.1
2.5 kV (peak value); 1 MHz; τ = 15 µs;
400 pulses per s; test duration 2 s; R
i
= 200 Ω
Fast transient surge withstand cap.
IEEE Std C37.90.1
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms; repetition
rate 300 ms; both polarities: R
i
= 50 Ω; test duration
1 min
Radiated electromagnetic interference
IEEE Std C37.900.2
35 V/m; 25 MHz to 1000 MHz
Damped oscillations
IEC 60694, IEC 61000-4-12
2.5 kV (peak value), polarity alternating 100 kHz,
1 MHz, 10 MHz and 50 MHz,
R
L
= 200 Ω
Standard: EN 61000-6-3 (generic standard)
Radio Noise Voltage to Lines, Only Power Supply
Voltage IEC-CISPR 22
150 kHz to 30 MHz
Limit Class B
Radio Noise Field Strength IEC-CISPR 11 30 MHz to 1000 MHz Limit Class A
Standards: IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class 2
IEC 60068-2-6
sinusoidal
10 Hz to 60 Hz: ±0.075 mm amplitude;
60 Hz to 150 Hz: 1g acceleration
Frequency Sweep Rate 1 octave/min,
20 Cycles in 3 Orthogonal Axes
Shock
IEC 60255-21-2, Class 1
IEC 60068-2-27
Semi-sinusoidal
5 g acceleration, duration 11 ms,
each 3 shocks (in both directions of the 3 axes)
Seismic Vibration
IEC 60255-21-3, Class 1
IEC 60068-3-3
sinusoidal
1 Hz to 8 Hz: ±3.5 mm amplitude;
(Horizontal axis)
1 Hz to 8 Hz: ±1.5 mm amplitude;
(vertical axis)
8 Hz to 35 Hz: 1 g acceleration
(horizontal axis); 8 Hz to 35 Hz: 0.5 g acceleration
(vertical axis)
Frequency Sweep 1 octave/min
1 Cycle in 3 Orthogonal Axes
