4.22 Sensitive Earth Fault Protection (ANSI 51GN, 64R)
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
497
4.22 Sensitive Earth Fault Protection (ANSI 51GN, 64R)
Setting Ranges / Increments
Times
Dropout Ratios
Tolerances
Influencing Variables
Pickup current I
EE
> 2 mA to 1000 mA Increments 1 mA
Delay Time T
IEE
> 0.00 s to 60.00 s
or ∞ (ineffective)
Increments 0.01 s
Pickup current I
EE
>> 2 mA to 1000 mA Increments 1 mA
Delay time T
IEE
>> 0.00 s to 60.00 s
or ∞ (ineffective)
Increments 0.01 s
Measuring circuit supervision when used as rotor earth
fault protection I
EE
<
1.5 mA to 50.0 mA
or 0.0 mA (ineffective)
Increments 0.1 mA
Pickup Times approx. 50 ms
Dropout Times approx. 50 ms
Measuring Circuit Supervision (Delay) approx. 2 s
Pickup current I
EE
>, I
EE
>> approx. 0.95 or 1 mA
Measuring circuit supervision I
EE
< approx. 1.10 or 1 mA
Pickup current 1 % of setting value or 0.5 mA
Time Delay 1 % of setting value or 10 ms
Power supply direct voltage in range 0.8 ≤ U
Aux
/U
AuxN
≤ 1.15 ≤ 1 %
Temperature in range 23.00 °F (–5 °C) ≤ Θ
amb
≤ 131.00 °F (55 °C) ≤ 0.5 % / 10 K
Frequency in range 0.95 ≤ f/f
N
≤ 1.05 ≤ 1 %
Harmonics
- Up to 10 % 3rd harmonic
- Up to 10 % 5th harmonic
≤ 1 %
≤ 1 %
Note: For the purpose of high sensitivity, the linear range of the measuring input for the sensitive earth fault
acquisition is from 2 mA to 1600 mA.
