Appendix
A.5 Protocol-dependent Functions
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
570
A.5 Protocol-dependent Functions
Protocol IEC 60870-5-103 IEC 61850
Ethernet
(EN-100)
Profibus DP DNP3.0 Modbus
ASCII/RTU
Additional
Service Inter-
face (optional)
Function
Operational mea-
sured values
Yes (fixed values) Yes Yes Yes Yes Yes
Metered values Yes Yes Yes Yes Yes Yes
Fault Recording Yes Yes No. Only via
additional
service inter-
face
No. Only via
additional
service inter-
face
No. Only via
additional
service inter-
face
Yes
Remote protection
setting
No. Only via addi-
tional service in-
terface
No. Only via
additional
service inter-
face
No. Only via
additional
service inter-
face
No. Only via
additional
service inter-
face
No. Only via
additional
service inter-
face
Yes
User-defined indica-
tions and switching
objects
Yes Yes Yes Yes Yes Yes
Time synchroniza-
tion
Via Protocol;
DCF77/IRIG B;
Interface;
Binary Input
Via Protocol
(NTP);
DCF77/IRIG B;
Interface;
Binary Input
Via
DCF77/IRIG B;
Interface;
Binary Input
Protocol
Via Protocol;
DCF77/IRIG B;
Interface;
Binary Input
Via
DCF77/IRIG B;
Interface;
Binary Input
Protocol
Indications with time
stamp
Yes Yes Yes Yes Yes Yes
Commissioning tools
Measured value in-
dication blocking
Yes Yes No No No Yes
Test Mode Yes Yes No No No Yes
Physical mode Asynchronous Synchronous Asynchronous Asynchronous Asynchronous
Transmission Mode Cyclically/Event Cyclical-
ly/Event
Cyclically Cyclical-
ly/Event
Cyclically
Baudrate 4800 to 38400 Up tp
100 MBaud
Up to 1.5
MBaud
4800 to 19200 2400 to 19200 4800 to
115200
Type RS232
RS485
Optical Fiber
Ethernet TP RS485
Optical Fiber;
Double ring
RS485
Optical Fiber
RS485
Optical Fiber
RS232
RS485
