Technical Data
4.36 User-defined Functiones (CFC)
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
512
4.36 User-defined Functiones (CFC)
Function Modules and Possible Assignments to Task Levels
Function Module Explanation Task Level
MW_
BEARB
PLC1_
BEARB
PLC_
BEARB
SFS_
BEARB
ABSVALUE Magnitude Calculation X — — —
ADD Addition X X X X
ALARM Alarm clock X X X X
AND AND - Gate X X X X
FLASH Blink block X X X X
BOOL_TO_CO Boolean to Control
(conversion)
—X X—
BOOL_TO_DI Boolean to Double
Point (conversion)
—X XX
BOOL_TO_IC Bool to Internal SI,
Conversion
—X XX
BUILD_DI Create Double Point
Annunciation
—X XX
CMD_CANCEL Command cancelled X X X X
CMD_CHAIN Switching Sequence — X X —
CMD_INF Command Information — — — X
COMPARE Metered value compar-
ison
XX XX
CONNECT Connection — X X X
COUNTER Counter X X X X
DI_GET_STATUS Decode double point
indication
XX XX
DI_SET_STATUS Generate double point
indication with status
XX XX
D_FF D- Flipflop — X X X
D_FF_MEMO Status Memory for
Restart
XX XX
DI_TO_BOOL Double Point to
Boolean (conversion)
—X XX
DINT_TO_REAL Adaptor X X X X
DIST_DECODE Conversion double
point indication with
status to four single in-
dications with status
XX XX
DIV Division X X X X
DM_DECODE Decode Double Point X X X X
DYN_OR Dynamic OR X X X X
INT_TO_REAL Conversion X X X X
LIVE_ZERO Live-zero, non-linear
Curve
X———
LONG_TIMER Timer (max.1193h) X X X X
LOOP Feedback Loop X X — X
LOWER_SETPOINT Lower Limit X — — —
