Siemens SIPROTEC 7UM62 - Dimensions of Resistor Unit 7 XR6004-0 BA00 for Panel Surface Mounting

To Next Page

To Previous Page

Technical Data

4.39 Dimensions

SIPROTEC, 7UM62, Manual

C53000-G1176-C149-7, Release date 03.2010

534

4.39.11 Dimensions of Resistor Unit 7XR6004-0BA00 for Panel Surface Mounting

Figure 4-24 Dimensions of Resistor Unit 7XR6004-0BA00 for Panel Surface Mounting
