Siemens SIPROTEC 7UM62 User Manual

Appendix
A.10 Measured Values
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
616
A.10 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- IL< under current (IL<) Set Points(MV) - - - - - CFC CD DD
- Number of TRIPs (#of TRIPs=) Statistics - - - - - CFC CD DD
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CFC CD DD
605 I1 (positive sequence) (I1 =) Measurement 134 147 No 9 5 CFC CD DD
606 I2 (negative sequence) (I2 =) Measurement 134 147 No 9 6 CFC CD DD
621 U L1-E (UL1E=) Measurement 134 147 No 9 7 CFC CD DD
622 U L2-E (UL2E=) Measurement 134 147 No 9 8 CFC CD DD
623 U L3-E (UL3E=) Measurement 134 147 No 9 9 CFC CD DD
624 U L12 (UL12=) Measurement - - - - - CFC CD DD
625 U L23 (UL23=) Measurement - - - - - CFC CD DD
626 U L31 (UL31=) Measurement - - - - - CFC CD DD
627 Displacement voltage UE (UE =) Measurement 134 147 No 9 10 CFC CD DD
629 U1 (positive sequence) (U1 =) Measurement 134 147 No 9 11 CFC CD DD
630 U2 (negative sequence) (U2 =) Measurement - - - - - CFC CD DD
639 UE 3rd Harmonic Voltage Minimum (UE3h
min=)
Min/Max meter - - - - - CFC CD DD
640 UE 3rd Harmonic Voltage Maximum (UE3h
max=)
Min/Max meter - - - - - CFC CD DD
641 P (active power) (P =) Measurement 134 147 No 9 12 CFC CD DD
642 Q (reactive power) (Q =) Measurement 134 147 No 9 13 CFC CD DD
644 Frequency (Freq=) Measurement 134 147 No 9 15 CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
650 UE 3rd harmonic (UE3h =) Measurement - - - - - CFC CD DD
660 Remaining Time for Switch ON (T Rem.=) Meas. Thermal - - - - - CFC CD DD
661 Threshold of Restart Inhibit (Θ REST. =) Meas. Thermal - - - - - CFC CD DD
662 DC Current (I DC =) Measurement - - - - - CFC CD DD
669 SEF 100%: 20 Hz voltage stator circuit
(U20=)
Measurement - - - - - CFC CD DD
670 SEF 100%: 20 Hz current stator circuit (I20=) Measurement - - - - - CFC CD DD
693 REF(R,fn): Total Resistance (R total) (Rtot =) Measurement - - - - - CFC CD DD
696 REF(R,fn): Total Reactance (X total) (Xtot =) Measurement - - - - - CFC CD DD
697 REF(R,fn): Phase Angle of Z total (ϕ Ztot=) Measurement - - - - - CFC CD DD
700 REF(R,fn): Fault Resistance (R earth) (Re
=)
Measurement 134 148 No 9 5 CFC CD DD
721 Operat. meas. current L1 side 1 [%] is
(IL1S1=)
Measurement 134 148 No 9 1 CFC CD DD
722 Operat. meas. current L2 side 1 [%] is
(IL2S1=)
Measurement 134 148 No 9 2 CFC CD DD
723 Operat. meas. current L3 side 1 [%] is
(IL3S1=)
Measurement 134 148 No 9 3 CFC CD DD
724 Operat. meas. current L1 side 2 [%] is
(IL1S2=)
Measurement 134 147 No 9 1 CFC CD DD
725 Operat. meas. current L2 side 2 [%] is
(IL2S2=)
Measurement 134 147 No 9 2 CFC CD DD
726 Operat. meas. current L3 side 2 [%] is
(IL3S2=)
Measurement 134 147 No 9 3 CFC CD DD
755 REF(1-3Hz): Freq. of square-wave gen.
(fgen =)
Measurement - - - - - CFC CD DD
