Siemens SIPROTEC 7UM62 User Manual

Appendix
A.10 Measured Values
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
617
757 REF(1-3Hz): Volt. of square-wave gen.
(Ugen =)
Measurement - - - - - CFC CD DD
758 REF(1-3Hz): Curr. of rotor meas. circuit
(Imeas. =)
Measurement - - - - - CFC CD DD
759 REF(1-3 Hz): Charge at polarity rev.(Qc) (Qc
=)
Measurement - - - - - CFC CD DD
760 SEF100%: Prim. stator earth resistance
(RSEFp=)
Measurement - - - - - CFC CD DD
761 REF(1-3Hz): Fault Resistance (R earth) (R
earth=)
Measurement 134 148 No 9 6 CFC CD DD
762 SEF100%: Bias volt. for stator circuit (U
SEF=)
Measurement - - - - - CFC CD DD
763 SEF100%: Earth curr. in stator circuit (I
SEF=)
Measurement - - - - - CFC CD DD
764 SEF100%: Stator earth resistance (R SEF=) Measurement 134 148 No 9 7 CFC CD DD
765 (U/Un) / (f/fn) (U/f =) Measurement 134 147 No 9 16 CFC CD DD
766 Calculated temperature (U/f) (U/f th. =) Meas. Thermal - - - - - CFC CD DD
769 Displacement voltage U Interturn (U I/T =) Measurement - - - - - CFC CD DD
801 Temperat. rise for warning and trip (Θ/Θtrip
=)
Meas. Thermal - - - - - CFC CD DD
802 Temperature rise for phase L1 (Θ/ΘtripL1=) Meas. Thermal - - - - - CFC CD DD
803 Temperature rise for phase L2 (Θ/ΘtripL2=) Meas. Thermal - - - - - CFC CD DD
804 Temperature rise for phase L3 (Θ/ΘtripL3=) Meas. Thermal - - - - - CFC CD DD
805 Temperature of Rotor (ΘR/ΘRmax =) Meas. Thermal - - - - - CFC CD DD
827 Sensitive Current IEE-B (IEE-B=) Measurement - - - - - CFC CD DD
828 Senstive Earth Current 1 (IEE1=) Measurement 134 148 No 9 4 CFC CD DD
829 Senstive Earth Current 2 (IEE2=) Measurement 134 147 No 9 4 CFC CD DD
831 3I0 (zero sequence) (3I0 =) Measurement - - - - - CFC CD DD
832 U0 (zero sequence) (U0 =) Measurement - - - - - CFC CD DD
857 Positive Sequence Minimum (I1 Min=) Min/Max meter - - - - - CFC CD DD
858 Positive Sequence Maximum (I1 Max=) Min/Max meter - - - - - CFC CD DD
874 U1 (positive sequence) Voltage Minimum (U1
Min =)
Min/Max meter - - - - - CFC CD DD
875 U1 (positive sequence) Voltage Maximum
(U1 Max =)
Min/Max meter - - - - - CFC CD DD
876 Active Power Minimum (PMin=) Min/Max meter - - - - - CFC CD DD
877 Active Power Maximum (PMax=) Min/Max meter - - - - - CFC CD DD
878 Reactive Power Minimum (QMin=) Min/Max meter - - - - - CFC CD DD
879 Reactive Power Maximum (QMax=) Min/Max meter - - - - - CFC CD DD
882 Frequency Minimum (fMin=) Min/Max meter - - - - - CFC CD DD
883 Frequency Maximum (fMax=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CFC CD DD
894 DC voltage (U DC =) Measurement - - - - - CFC CD DD
896 REF(R,fn): Injected Voltage (U RE) (U RE =) Measurement - - - - - CFC CD DD
897 REF(R,fn): Curr. in the Circuit (I RE) (I RE =) Measurement - - - - - CFC CD DD
901 Power Factor (PF =) Measurement 134 147 No 9 14 CFC CD DD
902 Power angle (PHI=) Measurement - - - - - CFC CD DD
903 Resistance (R=) Measurement - - - - - CFC CD DD
904 Reactance (X=) Measurement - - - - - CFC CD DD
909 Excitation voltage (Uexcit.=) Measurement - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
