Appendix
A.10 Measured Values
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
618
■
910 Calculated rotor temp. (unbal. load) (Therm-
Rep.=)
Meas. Thermal - - - - - CFC CD DD
911 Cooling medium temperature (AMB.TEMP =) Meas. Thermal - - - - - CFC CD DD
924 Wp Forward (WpForward) Energy 133 51 No 205 - CFC CD DD
925 Wq Forward (WqForward) Energy 133 52 No 205 - CFC CD DD
928 Wp Reverse (WpReverse) Energy 133 53 No 205 - CFC CD DD
929 Wq Reverse (WqReverse) Energy 133 54 No 205 - CFC CD DD
995 SEF100%: Phase angle in stator circuit (ϕ
SEF=)
Measurement - - - - - CFC CD DD
996 Transducer 1 (Td1=) Measurement - - - - - CFC CD DD
997 Transducer 2 (Td2=) Measurement - - - - - CFC CD DD
998 Transducer 3 (Td3=) Measurement - - - - - CFC CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Meas. Thermal 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Meas. Thermal 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Meas. Thermal 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Meas. Thermal 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Meas. Thermal 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Meas. Thermal 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Meas. Thermal 134 146 No 9 7 CFC CD DD
1075 Temperature of RTD 8 (Θ RTD 8 =) Meas. Thermal 134 146 No 9 8 CFC CD DD
1076 Temperature of RTD 9 (Θ RTD 9 =) Meas. Thermal 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10 =) Meas. Thermal 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11 =) Meas. Thermal 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12 =) Meas. Thermal 134 146 No 9 12 CFC CD DD
7740 Phase angle in phase IL1 side 1 (ϕIL1S1=) Measurement - - - - - CFC CD DD
7741 Phase angle in phase IL2 side 1 (ϕIL2S1=) Measurement - - - - - CFC CD DD
7742 IDiffL1(I/Inominal object [%]) (IDiffL1=) Meas. Dif/Rest. - - - - - CFC CD DD
7743 IDiffL2(I/Inominal object [%]) (IDiffL2=) Meas. Dif/Rest. - - - - - CFC CD DD
7744 IDiffL3(I/Inominal object [%]) (IDiffL3=) Meas. Dif/Rest. - - - - - CFC CD DD
7745 IRestL1(I/Inominal object [%]) (IRestL1=) Meas. Dif/Rest. - - - - - CFC CD DD
7746 IRestL2(I/Inominal object [%]) (IRestL2=) Meas. Dif/Rest. - - - - - CFC CD DD
7747 IRestL3(I/Inominal object [%]) (IRestL3=) Meas. Dif/Rest. - - - - - CFC CD DD
7749 Phase angle in phase IL3 side 1 (ϕIL3S1=) Measurement - - - - - CFC CD DD
7750 Phase angle in phase IL1 side 2 (ϕIL1S2=) Measurement - - - - - CFC CD DD
7759 Phase angle in phase IL2 side 2 (ϕIL2S2=) Measurement - - - - - CFC CD DD
7760 Phase angle in phase IL3 side 2 (ϕIL3S2=) Measurement - - - - - CFC CD DD
30654 I0-Diff REF (I/Inominal object [%]) (I0-Diff=) Meas. Dif/Rest. - - - - - CFC CD DD
30655 I0-Rest REF (I/Inominal object [%]) (I0-
Rest=)
Meas. Dif/Rest. - - - - - CFC CD DD
30659 3I0-1 REF (I/Inominal object [%]) (3I0-1 =) Meas. Dif/Rest. - - - - - CFC CD DD
30660 3I0-2 REF (I/Inominal object [%]) (3I0-2 =) Meas. Dif/Rest. - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
