Siemens SIPROTEC 7UM62 User Manual

Technical Data
4.1 General
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
457
4.1.4 Communication Interfaces
Operating Interface
Service / Modem Interface
System Interface
Connection Front side, non-isolated, RS232,
9-pin DSUB port for connection of a PC
Operation With DIGSI
Transmission Speed min. 4 800 Bd to 115 200 Bd
Factory setting: 38 400 Bd;
Parity: 8E1
bridgeable distance 15 m
Connection isolated interface for data transfer
Operation With DIGSI
Transmission Speed min. 4,800 Bd to 115,200 Bd
Factory setting: 38,400 Bd;
Parity: 8E1
RS232/RS485 RS232/RS485 according to the ordering
variant
Connection for flush-mounted
case
Rear panel, mounting location "C"
9-pole DSUB port
Surface-mounting case At the console housing mounted case on the
case bottom;
Shielded data cable
Test voltage AC 500 V, 50 Hz
RS232
bridgeable distance 15 m
RS485
bridgeable distance 1,000 m
IEC 60870-5-103
RS232/RS485
Acc. to ordered variant
Isolated interface for data transfer to a
master terminal
RS232
Connection for flush mounted
case
Rear panel, mounting location "B"
9-pole DSUB port
For panel surface-mounted
case
in console housing at case bottom side
Test voltage 500 V; 50 Hz
Transmission speed min. 4,800 Bd,
max. 115,200 Bd
Factory setting
38,400 Bd
Bridgeable distance 15 m / 50 feet
