Functions
2.41 Analog Outputs
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
281
2.41.3 Settings
Addr. Parameter Setting Options Default Setting Comments
7301 20 mA (B1/1) = 10.0 .. 1000.0 % 200.0 % 20 mA (B1/1) correspond to
7302 MIN VALUE(B1/1) 0.0 .. 5.0 mA 1.0 mA Output value (B1/1) valid from
7303 20 mA (B2/1) = 10.0 .. 1000.0 % 200.0 % 20 mA (B2/1) correspond to
7304 MIN VALUE(B2/1) 0.0 .. 5.0 mA 1.0 mA Output value (B2/1) valid from
7305 20 mA (D1/1) = 10.0 .. 1000.0 % 200.0 % 20 mA (D1/1) correspond to
7306 MIN VALUE(D1/1) 0.0 .. 5.0 mA 1.0 mA Output value (D1/1) valid from
7307 20 mA (D2/1) = 10.0 .. 1000.0 % 200.0 % 20 mA (D2/1) correspond to
7308 MIN VALUE(D2/1) 0.0 .. 5.0 mA 1.0 mA Output value (D2/1) valid from
7310 MIN. VALUE B1/2 -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (B1/2)
7311 MIN.OUTPUT B1/2 0 .. 10 mA 4 mA Minimum Current Output Value
(B1/2)
7312 MAX. VALUE B1/2 10.00 .. 200.00 % 100.00 % Maximum Percentage Output
Value (B1/2)
7313 MAX.OUTPUT B1/2 10 .. 22 mA; 0 20 mA Maximum Current Output Value
(B1/2)
7320 MIN. VALUE B2/2 -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (B2/2)
7321 MIN.OUTPUT B2/2 0 .. 10 mA 4 mA Minimum Current Output Value
(B2/2)
7322 MAX. VALUE B2/2 10.00 .. 200.00 % 100.00 % Maximum Percentage Output
Value (B2/2)
7323 MAX.OUTPUT B2/2 10 .. 22 mA; 0 20 mA Maximum Current Output Value
(B2/2)
7330 MIN. VALUE D1/2 -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (D1/2)
7331 MIN.OUTPUT D1/2 0 .. 10 mA 4 mA Minimum Current Output Value
(D1/2)
7332 MAX. VALUE D1/2 10.00 .. 200.00 % 100.00 % Maximum Percentage Output
Value (D1/2)
7333 MAX.OUTPUT D1/2 10 .. 22 mA; 0 20 mA Maximum Current Output Value
(D1/2)
7340 MIN. VALUE D2/2 -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (D2/2)
7341 MIN.OUTPUT D2/2 0 .. 10 mA 4 mA Minimum Current Output Value
(D2/2)
7342 MAX. VALUE D2/2 10.00 .. 200.00 % 100.00 % Maximum Percentage Output
Value (D2/2)
7343 MAX.OUTPUT D2/2 10 .. 22 mA; 0 20 mA Maximum Current Output Value
(D2/2)
