Functions
2.42 Monitoring Functions
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
288
2.42.1.6 Information List
8107 BAL. FACT. I S2 0.10 .. 0.90 0.50 Balance Factor for Current
Monitor S2
8108 SUM.thres. U 10 .. 200 V 10 V Summation Thres. for Volt.
Monitoring
8109 SUM.Fact. U 0.60 .. 0.95 ; 0 0.75 Factor for Volt. Sum. Mon-
itoring
8110 ΣI THRESHOLD S1 5A 0.25 .. 10.00 A 0.50 A Summated Cur. Mon.
Threshold on Side 1
1A 0.05 .. 2.00 A 0.10 A
8111 ΣI FACTOR S1 0.00 .. 0.95 0.10 Summated Current Mon.
Factor on Side 1
8112 ΣI THRESHOLD S2 5A 0.25 .. 10.00 A 0.50 A Summated Cur. Mon.
Threshold on Side 2
1A 0.05 .. 2.00 A 0.10 A
8113 ΣI FACTOR S2 0.00 .. 0.95 0.10 Summated Current Mon.
Factor on Side 2
No. Information Type of In-
formation
Comments
161 Fail I Superv. OUT Failure: General Current Supervision
164 Fail U Superv. OUT Failure: General Voltage Supervision
165 Fail Σ U Ph-E OUT Failure: Voltage Summation Phase-Earth
167 Fail U balance OUT Failure: Voltage Balance
171 Fail Ph. Seq. OUT Failure: Phase Sequence
176 Fail Ph. Seq. U OUT Failure: Phase Sequence Voltage
197 MeasSup OFF OUT Measurement Supervision is switched OFF
230 Fail. Σ I Side1 OUT Failure: Current Summation on Side 1
231 Fail. Σ I Side2 OUT Failure: Current Summation on Side 2
265 FailPh.Seq I S1 OUT Failure: Phase Sequence I side 1
266 FailPh.Seq I S2 OUT Failure: Phase Sequence I side 2
571 Fail. Isym 1 OUT Fail.: Current symm. supervision side 1
572 Fail. Isym 2 OUT Fail.: Current symm. supervision side 2
Addr. Parameter C Setting Options Default Setting Comments
