Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
543
1)
Cannot be delivered in connection with 9th digit = „B“. If an optical interface is needed, order RS485, plus the necessary
converter.
2)
Cannot be delivered in connection with 9th digit = „B“. Only EN100 electrical possible (see Table A-1)
Table A-1 Additional device/module for surface-mounted housing
1)
The OLM converter requires an operating voltage of 24 VDC. If the operating voltage is > 24 VDC the additional power
supply 7XV5810-0BA00 is required.
1)
RTD Box 7XV5662-*AD10
2)
If you want to run the RTD-Box at an optical interface, you need also the RS485-FO-converter 7XV5650–0*A00.
Additional Information L Pos. 17 Pos. 18 Pos. 19
(Port B)
Profibus DP Slave, RS485 L 0 A
Profibus DP Slave, optical 820 nm, double ring, ST connector L 0 B
1)
Modbus electrical RS485 L 0 D
Modbus, 820 nm, optical, ST connector L 0 E
1)
DNP3.0, RS485 L0G
DNP3.0, 820 nm, optical, ST connector L 0 H
1)
IEC 61850, electrical with EN100, with RJ45 connector L 0 R
IEC 61850, optical with EN100, with ST connector L 0 S
2)
Optical interfaces are not possible with surface mounting housings. Please order in this case a device with the appropriate
electrical RS485 interface, and the additional OLM converters listed in Table A-1.
Protocol Converter
Module
Order No. Remark
Profibus DP
SIEMENS OLM
1)
6GK1502-2CB10 For single ring
6GK1502-3CB10 For double ring
Modbus RS485/FO
7XV5651-0BA00 –
DNP 3.0 820 nm RS485/FO
Service Interface (Port C) Pos. 12
DIGSI, Modem RS232 1
DIGSI, Modem/RTD box RS485 2
with analog output interface (port D) see Additional Information M 9
Additional information M Pos. 17 Pos. 18 Pos. 19
(Port C)
DIGSI, Modem RS232 M 1
DIGSI, Modem/RTD box RS485 M 2
(Port D) M
RTD Box
1)
, optical 820 nm, ST connector
2)
MA
RTD-Box
1)
, electrical RS 485 M F
Analog outputs 2 x (0 to 20 mA) M K
