2.45 External Trip Functions
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
314
Addr. Parameter Setting Options Default Setting Comments
8601 EXTERN TRIP 1 OFF
ON
Block relay
OFF External Trip Function 1
8602 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 1 Time Delay
8701 EXTERN TRIP 2 OFF
ON
Block relay
OFF External Trip Function 2
8702 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 2 Time Delay
8801 EXTERN TRIP 3 OFF
ON
Block relay
OFF External Trip Function 3
8802 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 3 Time Delay
8901 EXTERN TRIP 4 OFF
ON
Block relay
OFF External Trip Function 4
8902 T DELAY 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 4 Time Delay
