Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
382
Table 3-20 Jumper setting for activating/deactivating the f
g
≈ 10 Hz low-pass filter of measuring transducer
3
Note
The jumper settings must correspond to the mode set at addresses 295, 296 (voltage or current input) and
297 (with/without filter). Otherwise the device is blocked and outputs an alarm. After any changes to the jumper
settings, you should therefore immediately change the corresponding parameter settings using DIGSI.
Note
Unused measuring transducers should be shorted at the input terminals!
Jumpers X71, X72 and X73 on the input/output module C-I/O-6 are used to set the bus address and must not
be changed. The following table lists the jumper presettings.
Table 3-21 Jumper settings of the Bus Address of the input/output board C-I/O-6
Jumper Low-Pass Filter Inactive Low-Pass Filter Active Presetting
X91 1-2 2-3 2-3
X69 1-2 2-3 2-3
Jumper Factory Setting
X71 (AD0) 1-2 (H)
X72 (AD1) 2-3 (L)
X73 (AD2) 1-2 (H)
