Functions
2.4 Functional Scope
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
50
173 ANALOGOUTP B1/1 Disabled
I1 [%]
I2 [%]
IEE1 [%]
IEE2 [%]
U1 [%]
U0 [%]
U03H [%]
|P| [%]
|Q| [%]
|S| [%]
f [%]
U/f [%]
PHI [%]
|PF| [%]
ΘR/ΘRmax [%]
Θ/Θtrip [%]
RE REF [%]
RE REF 1-3Hz[%]
RE SEF100 [%]
Disabled Analog Output B1/1 (Port B)
174 ANALOGOUTP B2/1 Disabled
I1 [%]
I2 [%]
IEE1 [%]
IEE2 [%]
U1 [%]
U0 [%]
U03H [%]
|P| [%]
|Q| [%]
|S| [%]
f [%]
U/f [%]
PHI [%]
|PF| [%]
ΘR/ΘRmax [%]
Θ/Θtrip [%]
RE REF [%]
RE REF 1-3Hz[%]
RE SEF100 [%]
Disabled Analog Output B2/1 (Port B)
Addr. Parameter Setting Options Default Setting Comments
