Siemens SIPROTEC 7UM62 User Manual

Functions
2.4 Functional Scope
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
52
190 RTD-BOX INPUT Disabled
Port C
Port D
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
200 ANALOGOUTP B1/2 Disabled
P [%]
Q [%]
S [%]
f [%]
PF [%]
PHI [%]
U1 [%]
I2 [%]
I1 [%]
Disabled Analog Output B1/2 (Port B)
201 ANALOGOUTP B2/2 Disabled
P [%]
Q [%]
S [%]
f [%]
PF [%]
PHI [%]
U1 [%]
I2 [%]
I1 [%]
Disabled Analog Output B2/2 (Port B)
202 ANALOGOUTP D1/2 Disabled
P [%]
Q [%]
S [%]
f [%]
PF [%]
PHI [%]
U1 [%]
I2 [%]
I1 [%]
Disabled Analog Output D1/2 (Port D)
203 ANALOGOUTP D2/2 Disabled
P [%]
Q [%]
S [%]
f [%]
PF [%]
PHI [%]
U1 [%]
I2 [%]
I1 [%]
Disabled Analog Output D2/2 (Port D)
Addr. Parameter Setting Options Default Setting Comments
