Siemens SIPROTEC 7UM62 - Page 574

Appendix
A.6 Functional Scope
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
574
175 ANALOGOUTP D1/1 Disabled
I1 [%]
I2 [%]
IEE1 [%]
IEE2 [%]
U1 [%]
U0 [%]
U03H [%]
|P| [%]
|Q| [%]
|S| [%]
f [%]
U/f [%]
PHI [%]
|PF| [%]
ΘR/ΘRmax [%]
Θ/Θtrip [%]
RE REF [%]
RE REF 1-3Hz[%]
RE SEF100 [%]
Disabled Analog Output D1/1 (Port D)
176 ANALOGOUTP D2/1 Disabled
I1 [%]
I2 [%]
IEE1 [%]
IEE2 [%]
U1 [%]
U0 [%]
U03H [%]
|P| [%]
|Q| [%]
|S| [%]
f [%]
U/f [%]
PHI [%]
|PF| [%]
ΘR/ΘRmax [%]
Θ/Θtrip [%]
RE REF [%]
RE REF 1-3Hz[%]
RE SEF100 [%]
Disabled Analog Output D2/1 (Port D)
180 FUSE FAIL MON. Disabled
Enabled
Enabled Fuse Failure Monitor
181 M.V. SUPERV Disabled
Enabled
Enabled Measured Values Supervision
182 Trip Cir. Sup. Disabled
2 Binary Inputs
1 Binary Input
Disabled Trip Circuit Supervision
185 THRESHOLD Disabled
Enabled
Enabled Threshold Supervision
186 EXT. TRIP 1 Disabled
Enabled
Enabled External Trip Function 1
187 EXT. TRIP 2 Disabled
Enabled
Enabled External Trip Function 2
188 EXT. TRIP 3 Disabled
Enabled
Enabled External Trip Function 3
189 EXT. TRIP 4 Disabled
Enabled
Enabled External Trip Function 4
Addr. Parameter Setting Options Default Setting Comments
