Siemens SIPROTEC 7UM62 User Manual

Appendix
A.7 Settings
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
577
281 BkrClosed I MIN P.System Data 1 5A 0.20 .. 5.00 A 0.20 A Closed Breaker Min. Current
Threshold
1A 0.04 .. 1.00 A 0.04 A
295 TRANSDUCER 1 P.System Data 1 10 V
4-20 mA
20 mA
10 V Transducer 1
296 TRANSDUCER 2 P.System Data 1 10 V
4-20 mA
20 mA
10 V Transducer 2
297 TRANSDUCER 3 P.System Data 1 with filter
without filter
with filter Transducer 3
302 CHANGE Change Group Group A
Group B
Binary Input
Protocol
Group A Change to Another Setting
Group
401 WAVEFORMTRIGGER Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
403 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 1.00 sec Max. length of a Waveform
Capture Record
404 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 4.00 sec 0.20 sec Captured Waveform Prior to
Trigger
405 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
406 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
610 FltDisp.LED/LCD Device Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
611 Spont. FltDisp. Device YES
NO
NO Spontaneous display of flt.an-
nunciations
615 T MIN LED HOLD Device 0 .. 60 min 5 min Minimum hold time of lachted
LEDs
640 Start image DD Device image 1
image 2
image 3
image 4
image 1 Start image Default Display
1108 ACTIVE POWER P.System Data 2 Generator
Motor
Generator Measurement of Active Power for
1201 O/C I> O/C Prot. I> OFF
ON
Block relay
OFF Overcurrent Time Protection I>
1202 I> O/C Prot. I> 5A 0.25 .. 100.00 A 6.75 A I> Pickup
1A 0.05 .. 20.00 A 1.35 A
1203 T I> O/C Prot. I> 0.00 .. 60.00 sec; ∞ 3.00 sec T I> Time Delay
1204 U< SEAL-IN O/C Prot. I> ON
OFF
OFF State of Undervoltage Seal-in
1205 U< O/C Prot. I> 10.0 .. 125.0 V 80.0 V Undervoltage Seal-in Pickup
1206 T-SEAL-IN O/C Prot. I> 0.10 .. 60.00 sec 4.00 sec Duration of Undervoltage Seal-in
1207A I> DOUT RATIO O/C Prot. I> 0.90 .. 0.99 0.95 I> Drop Out Ratio
1301 O/C I>> O/C Prot. I>> OFF
ON
Block relay
OFF Overcurrent Time Protection I>>
1302 I>> O/C Prot. I>> 5A 0.25 .. 100.00 A 21.50 A I>> Pickup
1A 0.05 .. 20.00 A 4.30 A
1303 T I>> O/C Prot. I>> 0.00 .. 60.00 sec; ∞ 0.10 sec T I>> Time Delay
1304 Phase Direction O/C Prot. I>> Forward
Reverse
Reverse Phase Direction
1305 LINE ANGLE O/C Prot. I>> -90 .. 90 ° 60 ° Line Angle
1401 O/C Ip O/C Prot. Ip OFF
ON
Block relay
OFF Inverse O/C Time Protection Ip
1402 Ip O/C Prot. Ip 5A 0.50 .. 20.00 A 5.00 A Ip Pickup
1A 0.10 .. 4.00 A 1.00 A
1403 T Ip O/C Prot. Ip 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
1404 TIME DIAL: TD O/C Prot. Ip 0.50 .. 15.00 ; ∞ 5.00 TIME DIAL: TD
Addr. Parameter Function C Setting Options Default Setting Comments
