Siemens SIPROTEC 7UM62 User Manual

Appendix
A.7 Settings
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
589
8517 MEAS. VALUE 9> Threshold Disabled
P
Q
Delta P
UL1E
UL2E
UL3E
UE
U0
U1
U2
UE3h
IEE1
IEE2
3I0
I1
I2
PHI
PF
Transducer 1
Disabled Measured Value for Threshold
MV9>
8518 THRESHOLD MV9> Threshold -200 .. 200 % 100 % Threshold of Measured Value
MV9>
8519 MEAS. VALUE 10< Threshold Disabled
P
Q
Delta P
UL1E
UL2E
UL3E
UE
U0
U1
U2
UE3h
IEE1
IEE2
3I0
I1
I2
PHI
PF
Transducer 1
Disabled Measured Value for Threshold
MV10<
8520 THRESHOLD MV10< Threshold -200 .. 200 % 100 % Threshold of Measured Value
MV10<
8601 EXTERN TRIP 1 External Trips OFF
ON
Block relay
OFF External Trip Function 1
8602 T DELAY External Trips 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 1 Time Delay
8701 EXTERN TRIP 2 External Trips OFF
ON
Block relay
OFF External Trip Function 2
8702 T DELAY External Trips 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 2 Time Delay
8801 EXTERN TRIP 3 External Trips OFF
ON
Block relay
OFF External Trip Function 3
8802 T DELAY External Trips 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 3 Time Delay
8901 EXTERN TRIP 4 External Trips OFF
ON
Block relay
OFF External Trip Function 4
8902 T DELAY External Trips 0.00 .. 60.00 sec; ∞ 1.00 sec Ext. Trip 4 Time Delay
9011A RTD 1 TYPE RTD-Box Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Pt 100 Ω RTD 1: Type
9012A RTD 1 LOCATION RTD-Box Oil
Ambient
Winding
Bearing
Other
Winding RTD 1: Location
9013 RTD 1 STAGE 1 RTD-Box -50 .. 250 °C; ∞ 100 °C RTD 1: Temperature Stage 1
Pickup
9014 RTD 1 STAGE 1 RTD-Box -58 .. 482 °F; ∞ 212 °F RTD 1: Temperature Stage 1
Pickup
Addr. Parameter Function C Setting Options Default Setting Comments
