Smartrise HYDRO:EVOLVED User Manual

Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 285
Fault Number
Fault Name
Description
36
PF BUF
Preflight failed for MR BUF input.
37
PF PIT
Preflight failed for MR PIT input.
38
PF GOV
Preflight failed for MR GOV input.
39
PF SFH
Preflight failed for MR SFH input.
40
PF SFM
Preflight failed for MR SFM input.
41
PF LFT
Preflight failed for MR LFT input.
42
PF LFM
Preflight failed for MR LFM input.
43
PF LFB
Preflight failed for MR LFB input.
44
PF LRT
Preflight failed for MR LRT input.
45
PF LRM
Preflight failed for MR LRM input.
46
PF LRB
Preflight failed for MR LRB input.
47
PF BYP H
Preflight failed for MR hall door bypass
input.
48
PF BYP C
Preflight failed for MR car door bypass
input.
49
PF MR INSP
Preflight failed for MR inspection input.
50
PF CPLD PICK BYP
Preflight after failing to pick CPLD bypass
relay (EB3).
51
PF MCU PICK BYP
Preflight after failing to pick MR bypass
relay (EB4).
52
PF MCU DROP GRIP
Preflight after failing to drop MR rope
gripper relay (EB2).
53
PF CPLD DROP GRIP
Preflight after failing to drop CPLD rope
gripper relay (EB1).
54
PF CPLD PICK GRIP
Preflight after failing to pick CPLD rope
gripper relay (EB1).
55
PF MCU PICK GRIP
Preflight after failing to pick MR rope
gripper relay (EB2).
56
PF MCU DROP BYP
Preflight after failing to drop MR bypass
relay (EB4).
57
PF CPLD DROP BYP
Preflight after failing to drop CPLD bypass
relay (EB3).
CT Board
1
STARTUP
CT processor has reset.
2
PF CT SW
Preflight failed for the CT-SF1 (Car top
switch) input.
3
PF ESC HATCH
Preflight failed for the CT-SF2 (Escape
hatch switch) input.
4
PF CAR SAFE
Preflight failed for the CT-SF3 (Car safeties)
input.
5
PF CT INSP
Preflight failed for the CT-SF4 (CT
inspection) input.
