Solar-Log 2000 User Manual

117
Configuration Menu
Battery Section
The following configuration options are available for connected batteries from the Battery menu (it
only appears when a battery is connected).
•
Battery size
Enter the battery size in Wh in this box.
•
Consumption meter includes battery charge
This box enables recording the battery charges from the consumption meter.
Fig.: Battery con guration with help text
Note!
The following components always have to be used for battery monitoring to work:
=> Inverters
=> Battery
=> Consumption meter
Note!
Refer to Chapter 17.2 “Battery Diagnostic” for more information on diagnostics and
visualization.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
