219
Accessing Diagnostic values
Similar to the History view, there are various values displayed in the graphic view. These values depend on
the particular connected device and/or configured control logic.
All of the values displayed in the key can be selected and deselected at anytime with a left-click to display
individual values (curve) or to display or hide all values (curves). With a right-click, all of the values (cur-
ves) other than the one selected can be hidden.
In the simulation, different view options can be selected for the production and consumption curves.
The following options can be selected:
Production curve
Zero line
Increasing
Decreasing
Constant (a fixed value in watts can be defined here)
Normal levels of irradiation
Very high levels of irradiation
Low levels of irradiation
Inconsistent levels of irradiation
Selected day (a particular day can be selected here)
Consumption curve
Zero line
Increasing
Decreasing
Constant (a fixed value in watts can be defined here)
Normal
Smooth
Jagged
Selected day (a particular day can be selected here)
There is the option to directly switch to the configuration of the Smart Energy switching group by cli
-
cking on the arrow symbol in the top right corner.
