223
Accessing Yield Data
•
The current day curve (graph on the left). There is also the option to display the previous five days
as a curve in this graph. Therefore, just click on the day value in the graph on the right.
•
The current day value as well as those from the previous 5 days (graph on the right). Move the
mouse above one of the bars to display the day value. Click on one of the bars to have it display in
the graph on the left as a curve.
Additional tabs can be selected in this view:
•
Energy flow
•
Table
Note
If the Solar-Log™ is just used as a consumption monitoring tool, the menu is limited
to
Current values, Consumption and System information.
All of the other menus are hidden.
Note
When only consumption meters are connected to the Solar-Log™, a large
consumption tachometer is displayed instead of the production tachometer in the
Current values | Cockpit menu.
