Connecting accessories
Note!
The measurement voltage must in effect be at least 10V or an exact measurement is not
possible.
•
Connect the Utility Meter to the RS485 bus of the Solar-Log™ according to the following diagram:
Wiring
the Utility Meter
Terminal block connec-
tor RS485 Solar-Log™
only Solar-Log 1000 and 2000
Utility meter
Terminal block
connector
Article Number: 255385
PIN
PIN
1 22
4 23
•
The RS485 bus must be terminated.
Install a 120 Ohm, 0.25 W resistor between pin 22 and 23 of the Utility Meter to terminate.
•
Configuring the Utility Meter from the display
Setting MODBUS Address (PRG 200 = 1)
Setting Baud rate RS485 (PRG 202 = 2)
Setting Mode (PRG 203 = 0)
Setting Current converter primary (PRG 000)
Setting Current converter secondary (PRG 001)
Setting Voltage converter primary (PRG 002)
Setting Voltage converter secondary (PRG 003)
Refer to the accompanying manual of the device for the UMG 104 configuration procedure.
Note!
The parameter settings need to be adjusted before device detection.
If the parameters differ, the Utility Meter will not be detected by the Solar-Log™.
•
Perform an inverter detection
See the installation manual, Chapter "Performing inverter detections."
•
Configure the Utility-Meter under Configuration | Devices | Configuration, select the correspon-
ding
Operating mode and click on Save.
Check
•
Does the Utility Meter display a positive value for inverters feeding power, the current output
(kW)?
If this is not the case, the current measurements are incorrectly connected.
If necessary, switch the polarity of measuring inputs.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
