WARNING
If the fork arms fall on your legs, feet or knees during
replacement, there is a risk of injury due to their
weight. The space to the left and right of the fork is a
danger area.
– Wear protective gloves and safety shoes when
changing the fork arms.
– Ensure that no one stands in the danger area!
– Do not pull on the fork arms.
– The fork arms must always be carried by two peo-
ple; if necessary, use a hoist.
NOTE
It is advisable to use a transport pallet to sup-
port the fork arms when they are being instal-
led or removed. The pallet size depends on
the size of fork arms in use. It should be large
enough that the fork arms do not protrude af-
ter being placed on the pallet.
●
This means the fork arms can be safely
placed down and transported.
●
Both fork arms can be pushed over onto
one side.
Operation
4
Lifting
248 56368011531 EN - 01/2021 - 05
