– Disconnect the battery male connector.
– Disconnect the potential equalisation con-
nection if necessary.
WARNING
Risk of crushing or shearing!
No one must stand directly beside the
battery or between the battery and the
lift truck when removing or inserting the
battery.
CAUTION
Potential for damage to the battery ca-
ble!
– Position the battery cable on the bat-
tery in such a way that it cannot be
crushed, either when removing or in-
serting the battery or when closing
the battery door.
– Open the battery lock (1).
NOTE
If the battery lock cannot be opened by hand,
the coupling pin (2) from the counterweight
can be used as a lever extension.
6219_901-009
Operation
4
Replacing and transporting the battery
420 56368011531 EN - 01/2021 - 05
