Battery designa-
tion
Capacity
[Ah]
Circuit Weight/
ballast
weight [kg]
Battery compartment di-
mensions [mm]
Tray
Length Width Height
5PzV 500 500
A 856 830 630 627 365
5PzV 550 550
5PzS 575 575
5PzS 625 625
6PzV 600 600
A 1064 830 738 627 366
6PzV 660 660
6PzS 690 690
6PzS 750 750
5TCSM 660 660
B
1
856 1030 529 627 315
5PzV 500 500
5PzV 550 550
5PzS 575 575
5PzS 625 650
NOTE
When converting to TENSOR
®
batteries, the
maximum speed of the truck must be limited
to 17 km/h for technical reasons. Contact the
authorised service centre regarding this mat-
ter.
Battery requirements for use in poten-
tially explosive areas
Batteries for use in potentially explosive areas
are designed and specifically tested in respect
of the zones and temperature ranges in which
they are to be used. The permitted area of use
is permanently and clearly indicated on the
nameplate of the battery.
– If you have any questions relating to the re-
quirements, contact your authorised service
centre.
– Observe the explosion-protection regula-
tions.
– Use only explosion-protected batteries and
connection assemblies.
– Use only a battery tray that is approved for
the potentially explosive area.
1
In some trucks, an adapter plate is required to support the battery and circuit B.
Technical data
6
Battery specifications
