8B-8 Air Bag System:

Terminal arrangement of SDM (viewed from harness side)

Connector “L29” (SDM connector)

2345678910111213141516171819202122232425

272829303132333435363738394041424344454647484950

I7RS0A820003-02

1. SDM Connector “L29”

Terminal

symbol

Circuit Terminal

Terminal

symbol

Circuit

L29-1 — — L29-27 IG Ignition switch (power source)

L29-2 WL “AIR BAG” warning right L29-28 E1 Ground

L29-3 D– Driver air bag (–) L29-29 — —

L29-4 D+ Driver air bag (+) L29-30 — —

L29-5 P+ Passenger air bag (+) L29-31 — —

L29-6 P– Passenger air bag (–) L29-32 ST DLC

L29-7 DP– Driver seat belt pretensioner (–) L29-33 — —

L29-8 DP+ Driver seat belt pretensioner (+) L29-34 — —

L29-9 PP+ Passenger seat belt pretensioner (+) L29-35 — —

L29-10 PP– Passenger seat belt pretensioner (–) L29-36 — —

L29-11 DS– Driver side-air bag (–) (If equipped) L29-37 ADS Air bag deployed signal for BCM

L29-12 DS+ Driver side-air bag (+) (If equipped) L29-38 — —

L29-13 PS+

Passenger side-air bag (+) (If

equipped)

L29-39 — —

L29-14 PS–

Passenger side-air bag (–) (If

equipped)

L29-40 — —

L29-15 — — L29-41 — —

L29-16 — — L29-42 — —

L29-17 — — L29-43 — —

L29-18 — — L29-44 SP– Passenger side-sensor (–)

L29-19 DC– Driver side curtain-air bag (–) L29-45 SP+ Passenger side-sensor (+)

L29-20 DC+ Driver side curtain-air bag (+) L29-46 SD+ Driver side-sensor (+)

L29-21 PC+ Passenger side curtain-air bag (+) L29-47 SD– Driver side-sensor (–)

L29-22 PC– Passenger side curtain-air bag (–) L29-48 — —

L29-23 — — L29-49 — —

L29-24 — — L29-50 FD+ Forward-sensor (+)

L29-25 — — L29-51 FD– Forward-sensor (–)

L29-26 — — — — —
