Air Conditioning System: Manual Type 7B-15
A/C System Inspection at ECM
S7RS0B7214004
Voltage Check
When checking voltage at ECM connector terminals related to A/C system, refer to “DTC P2101: Throttle Actuator
Control Motor Circuit Range / Performance in Section 1A”.
0.40 – 0.45
(4.0 – 4.5)
(57 – 64)
2.0 – 2.5
(20 – 25)
(285 – 355)
High pressure reading on
both low and high
pressure sides.
Overcharged A/C
system.
Adjust refrigerant to
specified amount.
Faulty condenser
cooling operation.
Clean condenser.
Faulty radiator cooling
fan operation.
Inspect and repair
radiator cooling fan.
High pressure reading on
both low and high
pressure sides.
Low pressure side tubing
is not cold when touched.
Presence of air in A/C
system
(Improperly
evacuated).
Replace receiver/
dryer.
Inspect quantity of
compressor oil and
presence of
contaminants in oil.
Evacuate system and
recharge with fresh
refrigerant.
0.45 – 0.55
(4.5 – 5.5)
(64 – 78)
High pressure reading on
both low and high
pressure sides.
Large amount of frost or
dew on the low pressure
side tubing.
Faulty expansion
valve.
Refrigerant flow is not
regulated properly.
Replace expansion
valve.
Condition
Possible cause CorrectionManifold gauge MPa (kg/cm
2
) (psi)
Detail
Lo Hi
