7B-46 Air Conditioning System: Automatic Type
Scan Tool Data
S7RS0B7224007
As the data values given in the following are standard values estimated on the basis of values obtained from the
normally operation vehicles by using a scan tool, use them as reference values. Even when the vehicles are in good
condition, there may be cases where the checked values do not fall within each specifies data range. Therefore,
judgement as abnormal should not be made by checking with these data alone.
Scan Tool Data Condition
Normal Condition / Reference
Value
) TEMP CONT
SWITCH
Each reference value is relative to the position of
temperature selector of HVAC control module.
Max Cool, 18.5 °C (65 °F), 19 °C (66
°C) – 31 °C (88 °F), 31.5 °C (89 °F),
Max Hot
) CABIN
TEMPERATURE
Reference value is relative to in-car temperature.
–6.5 °C – 57.25 °C
(20.3 °F – 135.05 °F)
) OUTSIDE AIR TEMP
Reference value is relative to outside air
temperature.
–23.3 °C – 65.95 °C
(–9.94 °F – 150.71 °F)
) EVAPORATOR
TEMP
Reference value is relative to temperature of
evaporator.
–29.7 °C – 59.55 °C
(–21.46 °F – 139.19 °F)
) COOLANT TEMP At specified idle speed after warming up. 80 °C – 100 °C (176 °F – 212 °F)
) SUN LOAD Reference value depends on the situation. 0 W/m
2
– 4447.8 W/m
2
)MODE CONT
SWITCH
Each reference value is relative to the position of air
flow selector of HVAC control module.
AUTO, FACE, B/L, FOOT, D/F, DER
) FAN CONT SWITCH
Each reference value is relative to the position of
blower speed selector of HVAC control module.
AUTO, OFF, 1st, 2nd – 7th, 8th
) FAN DESIRED VOLT
Reference value is relative to the position of blower
speed selector of HVAC control module.
0 – 16.0 V
) AIR MIX POS SEN
Reference value is relative to the position of
temperature selector of HVAC control module.
about 2.0 V (Max Hot)
about 4.0 V (Max Cool)
)MODE POS SENSOR
Reference value is relative to the position of air flow
selector of HVAC control module.
about 1.6 V (DEF)
about 4.0 V (VENT)
) A/C CONT SIG
A/C system is ON. ON
A/C system is OFF. OFF
) BLOWER LOAD SIG
Position of blower speed selector is 1st position or
more.
ON
Position of blower speed selector is OFF position. OFF
) AIR INTAKE MODE
Fresh air (FRE) mode is activated. FRE
Recirculation air (REC) mode is activated. REC
AUTO mode is activated. AUTO
) REFRIGERANT
PRESSURE
Engine running.
A/C ON (A/C is operating)
at ambient temperature:
30 °C (86 °F)
1470 – 1770 kPa For more details,
refer to pressure of high pressure
gauge under “A/C System
Performance Inspection”
A/C OFF (A/C is not
operating) at ambient
temperature: 30 °C (86
°F) and engine coolant
temperature: 90 ° – 100
°C
600 – 1000 kPa After longer than 10
min from A/C switch turned off
) A/C COMP CLUTCH Engine running.
A/C switch and blower
motor switch turned ON
ON
A/C switch and/or blower
motor switch turned OFF
OFF
) DFR INDICATOR
Defroster indicator lamp is lighted. ON
Defroster indicator lamp is not lighted. OFF
) VEHICLE SPEED At stop.
OFF
0 km/h (0 mph)
