10C-9 Immobilizer Control System:
DTC P1614: Transponder Response Error
S7RS0BA304008
Detecting Condition and Trouble Area
DTC Confirmation Procedure
1) Turn ignition switch to ON position.
2) Check DTC in ECM.
Troubleshooting
DTC P1615: ID Code Does Not Registered (Vehicle equipped with keyless start system only)
S7RS0BA304009
Circuit Description
When the transponder code of the ignition key is registered in ECM, the remote controller ID code is also registered in
ECM and keyless start control module at the same time.
DTC P1615 is detected only when the remote controller ID code cannot be registered in ECM and keyless start control
module when the ignition key is registered.
NOTE
Perform troubleshooting of DTC P1618 if both DTC P1615 and P1618 have been detected.
After replacing ECM, be sure to register the transponder code in the ignition key with ECM referring
to “Registration of the Ignition Key”. After replacing the keyless start control module of the vehicle
equipped with the keyless start system, be sure to register referring to “Registration of the Ignition
Key”.
Detecting Condition and Trouble Area
Detecting Condition Trouble Area
Transponder code in the transponder built in the ignition
key cannot be read through ICM.
Ignition key
•ICM
•ECM
Step Action Yes No
1 Was “Immobilizer Control System Check” performed? Go to Step 2. Go to “Immobilizer
Control System Check”.
2 DTC check of ECM
1) Check if DTC other than P1614 is detected referring to
“Diagnostic Trouble Code (DTC) Check”.
Is DTC other than P1614 detected?
Go to applicable DTC
diag. flow.
Go to Step 3.
3 Registration of ignition key in use with ECM
1) Register ignition key in use with ECM referring to
“Registration of the Ignition Key”.
Was registration of ignition key completed?
Unregistered ignition
key.
Go to step 4.
4 Registration of spare ignition key with ECM
1) Register spare ignition key with ECM referring to
“Registration of the Ignition Key”.
Was registration of spare ignition key completed?
Replace ignition key
which can not be
registered.
Substitute a known-
good ECM and recheck.
Detecting Condition Trouble Area
While registering the transponder code in the
transponder built in the ignition key in ECM, the keyless
start control module sent a signal to ECM indicating that
the ID code could not be registered.
The ID code could not be registered in the keyless start
control module or ECM.
Circuit between steering lock unit and keyless start
control module
CAN communication circuit
Steering lock unit
Keyless start control module
•ECM
