Page #87 background imageLoading...
Page #87 background image
Engine General Information and Diagnosis: 1A-37
TP SENSOR 2 VOLT (THROTTLE POSITION SENSOR
(SUB) OUTPUT VOLTAGE, V)
The TP sensor (sub) reading provides throttle valve
opening information in the form of voltage.
APP SENSOR 1 VOLT (ACCELERATOR PEDAL
POSITION (APP) SENSOR (MAIN) OUTPUT
VOLTAGE, V)
The APP sensor (main) reading provides accelerator
pedal opening information in the form of voltage.
APP SENSOR 2 VOLT (ACCELERATOR PEDAL
POSITION (APP) SENSOR (SUB) OUTPUT VOLTAGE,
V)
The APP sensor (sub) reading provides accelerator
pedal opening information in the form of voltage.
ACCEL POSITION (ABSOLUTE ACCELERATOR
PEDAL POSITION, %)
When accelerator pedal is at fully released position,
accelerator pedal is indicated as 0 – 5% and 90 – 100%
fully depressed position.
THROTTLE TARGET POSI (TARGET THROTTLE
VALVE POSITION, %)
Target throttle valve position is ECM internal parameter
which indicates the ECM requested throttle valve
position.
BATTERY CURRENT (A)
This parameter indicates electric load value (current
consumption) that detected by electric load current
sensor.
GENERATOR CONT DUTY (GENERATOR CONTROL
DUTY, %)
This parameter indicates generator control duty ratio that
controls production electricity of generator by ECM.
100%: No limitation for the generating
0%: Maximum limitation for the generating
GENERATOR FIELD DUTY (GENERATOR FIELD
COIL DUTY, %)
This parameter indicates operating rate (status of
production electricity) for generator by field coil duty
ratio.
100%: maximum operation.
0%: minimum operation.
Visual Inspection
S7RS0B1104008
Visually check the following parts and systems.
Inspection item Reference section
Engine oil – level, leakage “Engine Oil and Filter Change in Section 0B”
Engine coolant – level, leakage “Coolant Level Check in Section 1F”
Fuel – level, leakage “Fuel Lines and Connections Inspection in
Section 0B”
Air cleaner element – dirt, clogging “Air Cleaner Filter Inspection in Section 0B”
Battery – fluid level, corrosion of terminal “Battery Description in Section 1J”
Water pump belt – tension damage “Accessory Drive Belt Inspection in Section
0B”
Throttle valve – operating sound “Electric Throttle Body Assembly On-Vehicle
Inspection in Section 1C”
Vacuum hoses of air intake system – disconnection, looseness,
deterioration, bend
“Vacuum Hose and Purge Valve Chamber
Inspection in Section 1B”
Connectors of electric wire harness – disconnection, friction
Fuses – burning
Parts – installation, bolt – looseness
Parts – deformation
Other parts that can be checked visually
Also check the following items at engine start, if possible
Malfunction indicator lamp – Operation “Malfunction Indicator Lamp (MIL) Check”
Charge warning lamp – Operation “Generator Symptom Diagnosis in Section 1J”
Engine oil pressure warning lamp – Operation “Oil Pressure Switch Inspection in Section 9C”
Engine coolant temp. meter – Operation “ECT Sensor Inspection in Section 1C”
Fuel level meter – Operation “Fuel Level Sensor Inspection in Section 9C”
Tachometer – Operation
Abnormal air being inhaled from air intake system
Exhaust system – leakage of exhaust gas, noise
Other parts that can be checked visually
