5A-134 Automatic Transmission/Transaxle:
2nd Brake Piston Assembly Components
S7RS0B5106045
2nd Brake Piston Assembly Disassembly and
Reassembly
S7RS0B5106046
Disassembly
1) Apply compressed air (400 – 800 kPa, 4 – 8 kg/cm
2
,
57 – 113 psi) to oil hole (1) of 2nd brake cylinder (3)
to remove 2nd brake piston (2).
2) Remove inner O-ring (1) and outer O-ring (2).
I2RH0B510196-01
1. 2nd brake cylinder 3. Inner O-ring : Apply automatic transaxle fluid.
2. 2nd brake piston 4. Outer O-ring : Do not reuse.
I2RH0B510197-01
I2RH0B510198-01
