Air Bag System: 8B-35
DTC Troubleshooting
Step Action Yes No
1 1) With ignition switch OFF, disconnect contact coil
connector located under of the steering column.
2) Check proper connection to contact coil at terminal in
“G26” connector.
3) If OK, then connect special tools (B) and (C) to “G26”
connector disconnected in Step 1).
Special tool
(B): 09932-75010
(C): 09932–78340
4) Check SDM DTC.
With ignition switch ON, is DTC B1033 indicated?
Go to Step 2. Go to Step 4.
BASE OF COLUMN
(B)
(C)
"G26"
I4RS0A820014-01
To Next Page
