Suzuki SWIFT 2005 User Manual

Wiring Systems: 9A-26
L: Floor harness
L: ACC socket wire
L: License plate wire
R: Fuel pump wire
No./Color Connective position No./Color Connective position
L01/BLU BCM
L29/BRN (With
Side A/B,
Curtain A/B
System)
A/B SDM
L02/N Main harness (To E44)
L30/YEL (IF
EQPD)
Side air-bag inflator (Passenger side)
L03/YEL Main harness (To E45) L31/N Front door wire (Passenger side) (To J09)
L04/YEL J/B L32/YEL Instrument panel harness (To G04)
L05/N J/B L33/N Instrument panel harness (To G03)
L06/N J/B L34/N Front door switch (Passenger side)
L07/N Front door wire (Driver side) (To J01)
L35/N (IF
EQPD)
Passenger side-sensor
L10/BLK Pretensioner (Driver side) L36/BLK Pretensioner (Passenger side)
L11/N (IF
EQPD)
Driver side-sensor L37/N Rear door wire (L) (To J21)
L12/N Front door switch (Driver side) L38/N Wheel speed sensor (RL)
L13/N Rear door wire (R) (To J16) L39/N Antenna amplifier
L14/N Wheel speed sensor (RR) L40/N Rear door switch (L)
L15/GRY Fuel pump wire (To R01)
L41/BLK (IF
EQPD)
Side curtain air-bag (L)
L16/N Rear door switch (R) L42/N Rear end door wire (To O01)
L17/N High mounted stop light L43/BLK Rear combination light (L)
L18/BLK Side curtain air-bag (R) L51/GRY Instrument panel harness (To G43)
L19/GRY Luggage compartment light L53/N Diagnosis connector #3
L20/N Rear combination light (R)
L59/GRY (IF
EQPD)
Rear end antenna
L21/N License plate wire (To L22)
L60/BLK (IF
EQPD)
Rear fog light
L23/N (A/T) A/T shift lever
L61/N (IF
EQPD)
Seat heater (Driver side) and seat belt
switch
L24/GRY J/C
L62/N (IF
EQPD)
Seat heater (Passenger side)
L25/YEL Side air-bag inflator (Driver side)
L63/YEL (IF
EQPD)
Seat heater switch (Driver side)
L26/N Seat belt switch
L64/GRN (IF
EQPD)
Seat heater switch (Passenger side)
L27/BLK Parking brake switch
L65/BRN (IF
EQPD)
Inside antenna
L28/BLU ACC socket wire (To L44)
L66/BRN (IF
EQPD)
Luggage antenna
L29/PNK A/B SDM L74/BLU J/C
No./Color Connective position No./Color Connective position
L44/BLU Floor harness (To L28) L46/BLK ACC socket
No./Color Connective position No./Color Connective position
L22/N Floor harness (To L21) L48/N License plate light #2
L47/N License plate light #1
No./Color Connective position No./Color Connective position
R01/GRY Floor harness (To L15)
R03/N (IF
EQPD)
Sub fuel level sensor
R02/BLK Fuel pump and gauge
