9M-1
Exterior T
rim:
Body,
Cab and Acces
sories
Exterior T
rim
Rep
air Instructions
Roof Molding Component
s
S7RS0B9D06001
4
2
2
1
3
[A]
2
53 mm (2.09 in.)
I6RS0C9D000
1-01
[A]:
Roof
side weather-strip instal
lation position
3.
Roof molding clip (Push-in type)
: Install roof molding clip to speci
fied position on body with epoxy adhesive applied.
1.
Roof molding
4.
Windshield side garnish
2.
Roof side weather-strip
